Part Number: ADIS16060

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Complete angular rate digital gyroscope
14-bit resolution
Scalable measurement range
Initial range: ±80°/sec (typical)
Increase range with external resistor
Z-axis (yaw rate) response
SPI digital output interface
High vibration rejection over wide frequency
5 V single-supply operation
8.2 mm × 8.2 mm × 5.2 mm package

Part Number: ADIS16265

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Yaw rate gyroscope with range scaling ±80°/sec, ±160°/sec, and ±320°/sec settings
No external configuration required to start data collection
- Start-up time: 165 ms
- Sleep mode recovery time: 2.5 ms
Factory-calibrated sensitivity and bias
- Calibration temperature range: −40°C to +85°C
SPI-compatible serial interface
Relative angle displacement output
Embedded temperature sensor
Operating temperature range: −40°C to +105°C
2000 g shock survivability

Part Number: ADIS16260

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Yaw rate gyroscope with range scaling ±80°/sec, ±160°/sec, and ±320°/sec settings
No external configuration required to start data collection
- Start-up time: 165 ms
- Sleep mode recovery time: 2.5 ms
Factory-calibrated sensitivity and bias
- Calibration temperature: +25°C
SPI-compatible serial interface
Relative angle displacement output
Embedded temperature sensor
2000 g shock survivability
Operating temperature range: −40°C to +105°C

Part Number: ADIS16135

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Digital gyroscope system, ±300°/sec measurement range
In-run bias stability, ~6°/hour
~11°/hour over temperature: −40°C to +85°C
Autonomous operation and data collection
No external configuration commands required
Start-up time: 181 ms; sleep mode recovery: 5 ms
Factory-calibrated sensitivity and bias
Calibration temperature range: −40°C to +85°C
Single serial peripheral interface, SPI compatible

Part Number: ADIS16136

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

In-run bias stability, 4°/hour
Autonomous operation and data collection
- No external configuration commands required
- Start-up time: 180 ms; sleep mode recovery: 2.5 ms

Part Number: ADIS16137

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Digital gyroscope system, ±1000°/sec measurement range
In-run bias stability, 2.8°/hour
Autonomous operation and data collection
No external configuration commands required
Start-up time: 245 ms
Sleep mode recovery: 2.5 ms

Part Number: ADIS16201

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Dual-axis inclinometer/accelerometer measurements
12-, 14-bit digital inclination/acceleration sensor outputs
±1.7 g accelerometer measurement range
±90° inclinometer measurement range, linear output
12-bit digital temperature sensor output
Digitally controlled sensitivity and bias calibration
Digitally controlled sample rate

Part Number: ADIS16203

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

0° to 360° Inclinometer
- ±180 output format option
14-bit digital inclination outputs
- Linear output, 0.025° resolution
12-bit digital temperature sensor output
Digitally controlled bias calibration
Digitally controlled sample rate
Digitally controlled filtering
Digitally controlled direction/orientation

Part Number: ADIS16209

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Dual-mode inclinometer system
- Dual-axis, horizontal operation, ±90°
- Single-axis, vertical operation, ±180°
High accuracy, 0.1°
Digital inclination data, 0.025° resolution
Digital acceleration data, 0.244 mg resolution
±1.7 g accelerometer measurement range
Digital temperature sensor output
Digitally controlled bias calibration
Digitally controlled sample rate

Part Number: ADIS16240

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description: /

Part Number: ADIS16210

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital inclinometer system
- ±180° measurement range, roll and pitch axes
- ±90° gravity axis
- ±0.1° relative accuracy
Triaxial, digital accelerometer, high accuracy
- ±1.7 g measurement range
- ±0.05° axis-to-axis alignment
Digital internal temperature measurements
Digital internal power supply measurements
Programmable user calibration options
- Single command, frame alignment
- Manual accelerometer bias correction

Part Number: ADIS16003

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description: /

Part Number: ADIS16201

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Dual-axis inclinometer/accelerometer measurements
12-, 14-bit digital inclination/acceleration sensor outputs
±1.7 g accelerometer measurement range
±90° inclinometer measurement range, linear output
12-bit digital temperature sensor output
Digitally controlled sensitivity and bias calibration
Digitally controlled sample rate

Part Number: ADIS16006

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Dual-axis accelerometer
SPI digital output interface
Internal temperature sensor
Highly integrated; minimal external components
Bandwidth externally selectable
1.9 mg resolution at 60 Hz

Part Number: ADIS16203

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

0° to 360° Inclinometer
- ±180 output format option
14-bit digital inclination outputs
- Linear output, 0.025° resolution
12-bit digital temperature sensor output
Digitally controlled bias calibration
Digitally controlled sample rate
Digitally controlled filtering
Digitally controlled direction/orientation

Part Number: ADIS16209

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Dual-mode inclinometer system
- Dual-axis, horizontal operation, ±90°
- Single-axis, vertical operation, ±180°
High accuracy, 0.1°
Digital inclination data, 0.025° resolution
Digital acceleration data, 0.244 mg resolution
±1.7 g accelerometer measurement range
Digital temperature sensor output
Digitally controlled bias calibration
Digitally controlled sample rate

Part Number: ADIS16240

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description: /

Part Number: ADIS16210

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital inclinometer system
- ±180° measurement range, roll and pitch axes
- ±90° gravity axis
- ±0.1° relative accuracy
Triaxial, digital accelerometer, high accuracy
- ±1.7 g measurement range
- ±0.05° axis-to-axis alignment
Digital internal temperature measurements
Digital internal power supply measurements
Programmable user calibration options
- Single command, frame alignment
- Manual accelerometer bias correction

Part Number: ADIS16365

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxis digital gyroscope with digital range scaling
- ±75°/sec, ±150°/sec, ±300°/sec settings
- Tight orthogonal alignment: <0.05°
Triaxis digital accelerometer: ±18 g
Autonomous operation and data collection
- No external configuration commands required
- Start-up time: 180 ms
- Sleep mode recovery time: 4 ms
Factory-calibrated sensitivity, bias, and axial alignment
−40°C to +85°C calibration temperature range
SPI-compatible serial interface
Wide bandwidth: 330 Hz
Embedded temperature sensor

Part Number: ADIS16364

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxis digital gyroscope with digital range scaling
- ±75°/sec, ±150°/sec, ±300°/sec settings
- Tight orthogonal alignment: <0.05°
Triaxis digital accelerometer: ±5 g
Autonomous operation and data collection
- No external configuration commands required
- Start-up time: 180 ms
- Sleep mode recovery time: 4 ms
Factory-calibrated sensitivity, bias, and axial alignment
Calibration temperature range: −20°C to +70°C
SPI-compatible serial interface
Wide bandwidth: 330 Hz
Embedded temperature sensor

Part Number: ADIS16362

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxis digital gyroscope with digital range scaling
- ±75°/sec, ±150°/sec, ±300°/sec settings
- Tight orthogonal alignment: <0.05°
Triaxis digital accelerometer: ±1.7 g
Wide sensor bandwidth: 330 Hz
Autonomous operation and data collection
- No external configuration commands required
- Start-up time: 180 ms
- Sleep mode recovery time: 4 ms
Factory-calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −20°C to +70°C
SPI-compatible serial interface
Embedded temperature sensor

Part Number: ADIS16375

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxis digital gyroscope, ±300°/sec
- Tight orthogonal alignment: 0.05°
Triaxis digital accelerometer: ±18 g
Delta-angle/velocity calculations
Wide sensor bandwidth: 330 Hz
High sample rate: 2.460 kSPS
Autonomous operation and data collection
- No external configuration commands required
- Startup time: 500 ms
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C
SPI-compatible serial interface
Embedded temperature sensor

Part Number: ADIS16334

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial digital gyroscope with digital range scaling
- ±75°/sec, ±150°/sec, ±300°/sec settings
- Tight orthogonal alignment: <0.05°
Triaxial digital accelerometer: ±5 g
Wide sensor bandwidth: 330 Hz
Autonomous operation and data collection
- No external configuration commands required
- Start-up time: 180 ms
Factory-calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −20°C to +70°C
SPI-compatible serial interface
Embedded temperature sensor

Part Number: ADIS16485

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope, ±450°/sec dynamic range
- ±0.05° orthogonal alignment error
- 6°/hr in-run bias stability
- 0.3°/√hr angular random walk
- 0.01% nonlinearity
Triaxial, digital accelerometer, ±5 g
Triaxial, delta angle, and delta velocity outputs
Fast start-up time, ~500 ms
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C
SPI-compatible serial interface
Embedded temperature sensor

Part Number: ADIS16480

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Dynamic angle outputs
- Quaternion, Euler, rotation matrix
- 0.1° (pitch, roll) and 0.3° (yaw) static accuracy
Triaxial, digital gyroscope, ±450°/sec dynamic range
- ±0.05° orthogonal alignment error
- 6°/√hr in-run bias stability
- 0.3°/√hr angular random walk
- 0.01% nonlinearity
Triaxial, digital accelerometer, ±10 g
Triaxial, delta angle and delta velocity outputs
Triaxial, digital magnetometer, ±2.5 gauss
Digital pressure sensor, 300 mbar to 1100 mbar
Adaptive extended Kalman filter
- Automatic covariance computation
- Programmable reference reorientation
- Programmable sensor disturbance levels
- Configurable event-driven controls

Part Number: ADIS16448

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial digital gyroscope with digital range scaling
- ±250°/sec, ±500°/sec, ±1000°/sec settings
- Axis-to-axis alignment, <0.05°
Triaxial digital accelerometer, ±18 g minimum
Triaxial digital magnetometer, ±1.9 gauss minimum
Digital barometer, 10 mbar to 1200 mbar
- Calibrated pressure range: 300 mbar to 1100 mbar
Autonomous operation and data collection
- No external configuration commands required
- 205 ms start-up time
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C
SPI-compatible serial interface
- Burst mode read sequence with optional CRC-16

Part Number: ADIS16445

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial digital gyroscope with digital range scaling
- ±62°/sec, ±125°/sec, ±250°/sec settings
- Axis-to-axis alignment, <0.05°
Triaxial digital accelerometer, ±5 g minimum
Autonomous operation and data collection
- No external configuration commands required
- 175 ms start-up time
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C
SPI-compatible serial interface
Embedded temperature sensor

Part Number: ADIS16488A

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope, ±450°/sec dynamic range
- ±0.05° orthogonal alignment error
- 5.1°/hr in-run bias stability
- 0.26°/√hr angular random walk
- 0.01% nonlinearity
Triaxial, digital accelerometer, ±18 g
Triaxial, delta angle and delta velocity outputs
Triaxial, digital magnetometer, ±2.5 gauss
Digital pressure sensor, 300 mbar to 1100 mbar
Fast start-up time, ~500 ms
Factory-calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C

Part Number: ADIS16486

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial digital gyroscope, ±450°/sec dynamic range (minimum)

±0.018° axis to axis misalignment error (typical)
5.3°/hr in-run bias stability (typical)
0.25°/√hr angular random walk (typical)
0.01% FS nonlinearity

Triaxial digital accelerometer, ±18 g dynamic range (minimum)
Triaxial, delta angle, and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment

Calibration temperature range: −40°C to +85°C

SPI compatible
Single VDD power supply operation: 3.0 V to 3.6 V
2000 g mechanical shock survivability

Part Number: ADIS16460

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial digital gyroscope
- Measurement range: ±100°/sec (minimum)
- 8°/√hr (typical) in-run bias stability
- 0.12°/√hr (typical) angle random walk, x-axis
Triaxial digital accelerometer, ±5 g dynamic range
Autonomous operation and data collection
- No external configuration commands required
- Fast start-up time
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: 0°C ≤ T_A ≤ 70°C
Serial peripheral interface (SPI) data communications

Part Number: ADIS16490

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope, ±100°/sec dynamic range
±0.05° axis to axis misalignment error
±0.25° axis to package misalignment error
1.8°/hr in run bias stability
0.09°/√hr angular random walk
Triaxial, digital accelerometer, ±8 g
3.6 μg in run bias stability
Triaxial, delta angle and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
Calibration temperature range: −40°C to +85°C
Serial peripheral interface (SPI) compatible

Part Number: ADIS16489

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope, ±450°/sec dynamic range

±0.018° axis-to-axis misalignment error
5.3°/hr in-run bias stability
0.25°/√hr angular random walk
0.045°/sec nonlinearity

Triaxial, digital accelerometer, ±18 g dynamic range
Barometer, 300 mbar to 1100 mbar
Triaxial, delta angle and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment

Calibration temperature range: −40°C to +85°C

SPI compatible

Part Number: ADIS16467-3

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope
- ±125°/sec, ±500°/sec, ±2000°/sec dynamic range models
- 2°/hr in-run bias stability (ADIS16467-1)
0.15°/√hr angular random walk (ADIS16467-1 and ADIS16467-2)
±0.05° axis to axis misalignment error
Triaxial, digital accelerometer, ±40 g
- 13 μg in-run bias stability
Triaxial, delta angle, and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C

Part Number: ADIS16467-2

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope
- ±125°/sec, ±500°/sec, ±2000°/sec dynamic range models
- 2°/hr in-run bias stability (ADIS16467-1)
0.15°/√hr angular random walk (ADIS16467-1 and ADIS16467-2)
±0.05° axis to axis misalignment error
Triaxial, digital accelerometer, ±40 g
- 13 μg in-run bias stability
Triaxial, delta angle, and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C

Part Number: ADIS16467-1

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope
- ±125°/sec, ±500°/sec, ±2000°/sec dynamic range models
- 2°/hr in-run bias stability (ADIS16467-1)
0.15°/√hr angular random walk (ADIS16467-1 and ADIS16467-2)
±0.05° axis to axis misalignment error
Triaxial, digital accelerometer, ±40 g
- 13 μg in-run bias stability
Triaxial, delta angle, and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C

Part Number: ADIS16465-3

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope
- ±125°/sec, ±500°/sec, ±2000°/sec dynamic range models
- 2°/hr in-run bias stability (ADIS16465-1)
- 0.15°/√hr angular random walk (ADIS16465-1 and ADIS16465-2)
- ±0.05° axis to axis misalignment error
Triaxial, digital accelerometer, ±8 g
- 3.6 μg in-run bias stability
Triaxial, delta angle, and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C

Part Number: ADIS16465-2

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope
- ±125°/sec, ±500°/sec, ±2000°/sec dynamic range models
- 2°/hr in-run bias stability (ADIS16465-1)
- 0.15°/√hr angular random walk (ADIS16465-1 and ADIS16465-2)
- ±0.05° axis to axis misalignment error
Triaxial, digital accelerometer, ±8 g
- 3.6 μg in-run bias stability
Triaxial, delta angle, and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C

Part Number: ADIS16465-1

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope
- ±125°/sec, ±500°/sec, ±2000°/sec dynamic range models
- 2°/hr in-run bias stability (ADIS16465-1)
- 0.15°/√hr angular random walk (ADIS16465-1 and ADIS16465-2)
- ±0.05° axis to axis misalignment error
Triaxial, digital accelerometer, ±8 g
- 3.6 μg in-run bias stability
Triaxial, delta angle, and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C

Part Number: ADIS16497-3

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope
- ±125°/sec, ±450°/sec, ±2000°/sec range options
- ±0.05° axis to axis misalignment error
- ±0.25° (maximum) axis to package misalignment error
- 0.8°/hr in-run bias stability (ADIS16497-1)
- 0.09°/√hr angular random walk (ADIS16497-1)
Triaxial, digital accelerometer, ±40 g
- 13 μg in run bias stability
Triaxial, delta angle and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C

Part Number: ADIS16497-2

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope
- ±125°/sec, ±450°/sec, ±2000°/sec range options
- ±0.05° axis to axis misalignment error
- ±0.25° (maximum) axis to package misalignment error
- 0.8°/hr in-run bias stability (ADIS16497-1)
- 0.09°/√hr angular random walk (ADIS16497-1)
Triaxial, digital accelerometer, ±40 g
- 13 μg in run bias stability
Triaxial, delta angle and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C

Part Number: ADIS16497-1

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope
- ±125°/sec, ±450°/sec, ±2000°/sec range options
- ±0.05° axis to axis misalignment error
- ±0.25° (maximum) axis to package misalignment error
- 0.8°/hr in-run bias stability (ADIS16497-1)
- 0.09°/√hr angular random walk (ADIS16497-1)
Triaxial, digital accelerometer, ±40 g
- 13 μg in run bias stability
Triaxial, delta angle and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C

Part Number: ADIS16495-3

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope
- ±125°/sec, ±450°/sec, ±2000°/sec range options
- ±0.05° axis to axis misalignment error
- ±0.25° (maximum) axis to package misalignment error
- 0.8°/hr in-run bias stability (ADIS16495-1)
- 0.09°/√hr angular random walk (ADIS16495-1)
Triaxial, digital accelerometer, ±8 g
- 3.2 μg in run bias stability
Triaxial, delta angle and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C

Part Number: ADIS16495-2

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope
- ±125°/sec, ±450°/sec, ±2000°/sec range options
- ±0.05° axis to axis misalignment error
- ±0.25° (maximum) axis to package misalignment error
- 0.8°/hr in-run bias stability (ADIS16495-1)
- 0.09°/√hr angular random walk (ADIS16495-1)
Triaxial, digital accelerometer, ±8 g
- 3.2 μg in run bias stability
Triaxial, delta angle and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C

Part Number: ADIS16495-1

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope
- ±125°/sec, ±450°/sec, ±2000°/sec range options
- ±0.05° axis to axis misalignment error
- ±0.25° (maximum) axis to package misalignment error
- 0.8°/hr in-run bias stability (ADIS16495-1)
- 0.09°/√hr angular random walk (ADIS16495-1)
Triaxial, digital accelerometer, ±8 g
- 3.2 μg in run bias stability
Triaxial, delta angle and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C

Part Number: ADIS16477-3

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope
- ±125°/sec, ±500°/sec, ±2000°/sec range models
- 2°/hr in-run bias stability (ADIS16477-1)
- 0.15°/√hr angle random walk (ADIS16477-1 and ADIS16477-2)
- ±0.1° axis-to-axis misalignment error
Triaxial, digital accelerometer, ±40 g
- 13 μg in-run bias stability
Triaxial, delta angle and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C

Part Number: ADIS16477-2

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope
- ±125°/sec, ±500°/sec, ±2000°/sec range models
- 2°/hr in-run bias stability (ADIS16477-1)
- 0.15°/√hr angle random walk (ADIS16477-1 and ADIS16477-2)
- ±0.1° axis-to-axis misalignment error
Triaxial, digital accelerometer, ±40 g
- 13 μg in-run bias stability
Triaxial, delta angle and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C

Part Number: ADIS16477-1

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope
- ±125°/sec, ±500°/sec, ±2000°/sec range models
- 2°/hr in-run bias stability (ADIS16477-1)
- 0.15°/√hr angle random walk (ADIS16477-1 and ADIS16477-2)
- ±0.1° axis-to-axis misalignment error
Triaxial, digital accelerometer, ±40 g
- 13 μg in-run bias stability
Triaxial, delta angle and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C

Part Number: ADIS16475-3

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope
- ±125°/sec, ±500°/sec, ±2000°/sec range models
- 2°/hr in-run bias stability (ADIS16475-1)
- 0.15°/√hr angle random walk (ADIS16475-1 and ADIS16475-2)
- ±0.1° axis to axis misalignment error
Triaxial, digital accelerometer, ±8 g
- 3.6 μg in-run bias stability
Triaxial, delta angle and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C

Part Number: ADIS16475-2

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope
- ±125°/sec, ±500°/sec, ±2000°/sec range models
- 2°/hr in-run bias stability (ADIS16475-1)
- 0.15°/√hr angle random walk (ADIS16475-1 and ADIS16475-2)
- ±0.1° axis to axis misalignment error
Triaxial, digital accelerometer, ±8 g
- 3.6 μg in-run bias stability
Triaxial, delta angle and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C

Part Number: ADIS16475-1

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope
- ±125°/sec, ±500°/sec, ±2000°/sec range models
- 2°/hr in-run bias stability (ADIS16475-1)
- 0.15°/√hr angle random walk (ADIS16475-1 and ADIS16475-2)
- ±0.1° axis to axis misalignment error
Triaxial, digital accelerometer, ±8 g
- 3.6 μg in-run bias stability
Triaxial, delta angle and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C

Part Number: ADIS16470

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope, ±2000°/sec dynamic range
- 8°/hr in run bias stability
- 0.008°/sec/√Hz rms rate noise density
Triaxial, digital accelerometer dynamic range: ±40 g
- 13 μg in run bias stability
Triaxial, delta angle and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −10°C to +75°C
SPI compatible data communications

Part Number: ADIS16507-3

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope
- ±125°/sec, ±500°/sec, ±2000°/sec dynamic range models
- 2.3°/hr in-run bias stability (ADIS16507-1)
- 0.13°/√hr angular random walk, x-axis and y-axis, 1 σ (ADIS16507-1)
- ±0.25° axis to axis misalignment error
Triaxial, digital accelerometer, ±392 m/sec² dynamic range
- 125 μm/sec² in-run bias stability, x-axis and y-axis, 1 σ
Triaxial, delta angle and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C

Part Number: ADIS16507-2

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope
- ±125°/sec, ±500°/sec, ±2000°/sec dynamic range models
- 2.3°/hr in-run bias stability (ADIS16507-1)
- 0.13°/√hr angular random walk, x-axis and y-axis, 1 σ (ADIS16507-1)
- ±0.25° axis to axis misalignment error
Triaxial, digital accelerometer, ±392 m/sec² dynamic range
- 125 μm/sec² in-run bias stability, x-axis and y-axis, 1 σ
Triaxial, delta angle and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C

Part Number: ADIS16507-1

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope
- ±125°/sec, ±500°/sec, ±2000°/sec dynamic range models
- 2.3°/hr in-run bias stability (ADIS16507-1)
- 0.13°/√hr angular random walk, x-axis and y-axis, 1 σ (ADIS16507-1)
- ±0.25° axis to axis misalignment error
Triaxial, digital accelerometer, ±392 m/sec² dynamic range
- 125 μm/sec² in-run bias stability, x-axis and y-axis, 1 σ
Triaxial, delta angle and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C

Part Number: ADIS16505-3

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope
- ±125°/sec, ±500°/sec, ±2000°/sec dynamic range models
- 2.3°/hr in-run bias stability (ADIS16505-1)
- 0.13°/√hr angular random walk, x-axis and y-axis, 1 σ (ADIS16505-1)
- ±0.25° axis to axis misalignment error
Triaxial, digital accelerometer, ±78.4 m/sec² dynamic range
- 26.5 μm/sec² in-run bias stability (x-axis and y-axis)
Triaxial, delta angle and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C

Part Number: ADIS16505-2

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope
- ±125°/sec, ±500°/sec, ±2000°/sec dynamic range models
- 2.3°/hr in-run bias stability (ADIS16505-1)
- 0.13°/√hr angular random walk, x-axis and y-axis, 1 σ (ADIS16505-1)
- ±0.25° axis to axis misalignment error
Triaxial, digital accelerometer, ±78.4 m/sec² dynamic range
- 26.5 μm/sec² in-run bias stability (x-axis and y-axis)
Triaxial, delta angle and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C

Part Number: ADIS16505-1

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope
- ±125°/sec, ±500°/sec, ±2000°/sec dynamic range models
- 2.3°/hr in-run bias stability (ADIS16505-1)
- 0.13°/√hr angular random walk, x-axis and y-axis, 1 σ (ADIS16505-1)
- ±0.25° axis to axis misalignment error
Triaxial, digital accelerometer, ±78.4 m/sec² dynamic range
- 26.5 μm/sec² in-run bias stability (x-axis and y-axis)
Triaxial, delta angle and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C

Part Number: ADIS16500

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial, digital gyroscope

±2000°/sec dynamic range
8.1°/hr in-run bias stability
0.29°/√hr angular random walk, x-axis and y-axis, 1 σ
±0.25° axis to axis misalignment error

Triaxial, digital accelerometer, ±392 m/sec² dynamic range
- 125 μm/sec² in-run bias stability
Triaxial, delta angle and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment

Calibration temperature range: −10°C to +75°C

Part Number: ADIS16446

Manufacturer: Analog Devices

Category: Sensors and MEMS

Description:

Triaxial digital gyroscope with digital range scaling
- ±250°/sec, ±500°/sec, ±1000°/sec settings
- Axis to axis misalignment: ±0.05°
Triaxial digital accelerometer dynamic range: ±18 g minimum
Autonomous operation and data collection
- No external configuration commands required
- 205 ms typical power-on start-up time
Factory calibrated sensitivity, bias, and axial alignment
- Calibration temperature range: −40°C to +85°C
SPI-compatible
- Optional burst read sequence for fast data transfer

Part Number: VIPER12ADIP-E

Manufacturer: STMicroelectronics

Category: Power Management

Description: SMPS primary IC

Part Number: VIPER22ADIP-E

Manufacturer: STMicroelectronics

Category: Power Management

Description: Fixed frequency off line converter

Part Number: MAX6442KADIYD7+T

Manufacturer: Maxim

Category: Integrated Circuits (ICs)

Description: IC BATT MON MULT-CHEM 2C SOT23-8

Part Number: MAX6442KADIVD3+T

Manufacturer: Maxim

Category: Integrated Circuits (ICs)

Description: IC BATT MON MULT-CHEM 2C SOT23-8

Part Number: MAX6442KADIYD3+T

Manufacturer: Maxim

Category: Integrated Circuits (ICs)

Description: IC BATT MON MULT-CHEM 2C SOT23-8

Part Number: MAX6442KADIWD7+T

Manufacturer: Maxim

Category: Integrated Circuits (ICs)

Description: IC BATT MON MULT-CHEM 2C SOT23-8

Part Number: MAX6442KADIZD7+T

Manufacturer: Maxim

Category: Integrated Circuits (ICs)

Description: IC BATT MON MULT-CHEM 2C SOT23-8

Part Number: MAX6442KADIZD3+T

Manufacturer: Maxim

Category: Integrated Circuits (ICs)

Description: IC BATT MON MULT-CHEM 2C SOT23-8

Part Number: MAX6442KADIRD3+T

Manufacturer: Maxim

Category: Integrated Circuits (ICs)

Description: IC BATT MON MULT-CHEM 2C SOT23-8

Part Number: MAX6442KADIWD3+T

Manufacturer: Maxim

Category: Integrated Circuits (ICs)

Description: IC BATT MON MULT-CHEM 2C SOT23-8

Part Number: MAX6442KADIVD7+T

Manufacturer: Maxim

Category: Integrated Circuits (ICs)

Description: IC BATT MON MULT-CHEM 2C SOT23-8

Part Number: MAX6442KADIRD7+T

Manufacturer: Maxim

Category: Integrated Circuits (ICs)

Description: IC BATT MON MULT-CHEM 2C SOT23-8

Part Number: MAX6442KADITD3+T

Manufacturer: Maxim

Category: Integrated Circuits (ICs)

Description: IC BATT MON MULT-CHEM 2C SOT23-8

Part Number: MAX6442KADITD7+T

Manufacturer: Maxim

Category: Integrated Circuits (ICs)

Description: IC BATT MON MULT-CHEM 2C SOT23-8

Part Number: MAX6442KADISD7+T

Manufacturer: Maxim

Category: Integrated Circuits (ICs)

Description: IC BATT MON MULT-CHEM 2C SOT23-8

Part Number: MAX6442KADISD3+T

Manufacturer: Maxim

Category: Integrated Circuits (ICs)

Description: IC BATT MON MULT-CHEM 2C SOT23-8

Part Number: W63AH2NBVADI

Manufacturer: Winbond

Category: Memory

Description: 1GB LPDDR3, X32, 1066MHZ, INDUST

Part Number: W63AH6NBVADI

Manufacturer: Winbond

Category: Memory

Description: 1GB LPDDR3, X16, 1066MHZ, INDUST

Part Number: W63AH2NBVADI TR

Manufacturer: Winbond

Category: Memory

Description: 1GB LPDDR3, X32, 1066MHZ, INDUST

Part Number: W63AH6NBVADI TR

Manufacturer: Winbond

Category: Memory

Description: 1GB LPDDR3, X16, 1066MHZ, INDUST

Part Number: W63AH2NBVADI TR

Manufacturer: Winbond

Category: Memory

Description: 1GB LPDDR3, X32, 1066MHZ, INDUST

Part Number: W63AH6NBVADI TR

Manufacturer: Winbond

Category: Memory

Description: 1GB LPDDR3, X16, 1066MHZ, INDUST

Part Number: W63AH2NBVADI

Manufacturer: Winbond

Category: Memory

Description: 1GB LPDDR3, X32, 1066MHZ, INDUST

Part Number: W63AH6NBVADI

Manufacturer: Winbond

Category: Memory

Description: 1GB LPDDR3, X16, 1066MHZ, INDUST
